90-Degree Long-Radius Elbow for Construction

• warranty

  3 Years
  customized support

  OEM
• Technic

  FORGED
  Connectivity

  Welding
• shape

  Round
  head code

  Hexagon
• Overall Length

  1/2" - 12"
  Height

  1/2" - 12"
• Surface Treatment

  smooth
  Pressure

  Low Pressure
• System of Measurement

  INCH
  Mounting hole diameter

  1/2" - 12"
• Pipe Features

  corrosion resistant
  Pipe Class

  Not Rated
• Application

  Construction Engineering
  Thread Types

  NPT

This construction elbow listing describes a 90-degree long-radius design with an ASME B16.9 reference. Stainless Steel, Forged and Seamless appear in the title, while the selectable material is Carbon Steel. Establish the supplied material and production package before accepting the proposed component for the project.

Resolve supplied material and end geometry

Obtain actual grade, condition and traceability records to clarify the stainless title and carbon steel option. Neither description should be used as the final material specification without supporting documentation. The selected elbow needs one agreed material basis connected to its purchase and inspection requirements.

Welding is named in the title and table, but NPT is also listed. Request the actual end drawing and mating-pipe details to establish the connection. Specify the end preparation or thread requirements that apply, together with the inspections needed to accept the supplied configuration.

Review the long-radius drawing and production scope

Confirm the applicable ASME B16.9 edition and component scope, then define nominal size, measured bend radius, angle, center-to-end dimensions, outside diameter and wall thickness. Long Radius is a design reference rather than a supplied radius measurement, and the 1/2–12 inch option does not provide those dimensions.

Repeated size ranges under length, height and mounting-hole diameter are not drawing measurements. Round and Hexagon fields also need interpretation against the actual geometry. Request the manufacturing and inspection records supporting the Forged and Seamless references, with measurable surface criteria beyond smooth and corrosion resistant wording.

Agree numerical construction operating requirements
